Tekton Building Wrap
Tekton Building Wrap is a synthetic breathable wall wrap used as a barrier under direct and non-direct fixed wall cladding on timber and steel framed buildings. The product is a coated spun-bonded polypropylene, and is approximately 0.6mm thick. Tekton Building Wrap is supplied in rolls 2740mm x 37m and 1370mm x 37m. *Non-absorbent claddings must be installed over a drained cavity.
Features & Benefits
- Suitable for wind zones up to very high (and extra high over a rigid wall underlay)
- Tekton Building Wrap is fire retardant with a flammability rating of 0
- Suitable for use as an barrier for unlined walls, such as gable ends
- Superior water hold out
- 50-year durability.
- U.V Exposure of 60 days
- Optimal surfactant resistance (will not lose integrity if exposed to soaps, detergents and cleaning chemicals)
- Water column 8650mm (AATCC 127-1995)
- Branz appraised # 548 (2013)
Frequently Asked Questions
What is Tekton Building Wrap used for?
Tekton Building Wrap is a synthetic breathable wall wrap installed as a secondary weather-resistant barrier behind wall claddings on timber and steel framed buildings. It's a coated spun-bonded polypropylene, approximately 0.6mm thick, and forms part of the wider Marshall Weatherization System.
What wind zones is Tekton Building Wrap suitable for?
Tekton is suitable for wind zones up to very high, and extra high when installed over a rigid wall underlay.
Does Tekton Building Wrap need a cavity behind non-absorbent claddings?
Yes. Non-absorbent claddings must be installed over a drained cavity when used with Tekton Building Wrap.
How long can Tekton Building Wrap be left exposed before cladding goes on?
Tekton has a UV exposure rating of 60 days, giving installers a workable window between wrapping and cladding.
What is the flammability rating of Tekton building wrap?
Tekton building wrap carries a flammability rating of ≤5.
Is Tekton building wrap suitable as an air barrier?
Yes. Tekton building wrap is suitable as an air barrier, including for unlined walls such as gable ends.
What sizes does Tekton Building Wrap come in?
It's supplied in rolls of 2740mm x 37m and 1370mm x 37m.
Is Tekton Building Wrap BRANZ appraised?
Yes, BRANZ Appraisal #548 (2013).
How does Tekton Building Wrap compare to HYDRA Wall Underlay or HYDRA Classic?
All three are flexible synthetic wall underlays that act as a secondary weather-resistant barrier behind the cladding. All three are suitable behind brick veneer, and all three are suitable in extra high wind zones when installed over a rigid air barrier.
The main difference is the cladding each can sit behind. Tekton is a non-absorbent underlay, so non-absorbent claddings must be installed over a drained cavity. HYDRA Wall Underlay and HYDRA Classic are absorbent underlays. They can be used behind both absorbent and non-absorbent claddings, in direct fix and cavity applications.
